CELIKEL HARVESTER
Save time with Challenger 4, the world’s fastest silage machine…
The Challenger 4 silage machine has been developed by Çelikel engineers, who were inspired by the most durable and fastest animal in the world.
A new row-independent silage machine that can work with 150 hp tractors is on the field.
Now it’s time for competitors to think!
You will understand what we are saying when you see CHALLENGER 4. You will think that we are underselling this machine! CHALLENGER 4 is a world standard!
You will understand what we are saying when you see CHALLENGER 4. You will think that we are underselling this machine! CHALLENGER 4 is a world standard!
SHARPER, FASTER…
It can be the most desired machine in the sector.
Some want this machine because of its looks. Others want it for what others tell them about it. Some want it for performance, some for prestige, and some because it has a good secondhand selling price. And some just want it for no reason at all.
The most successful machine in the Turkish Agricultural Machine Sector! CHALLENGER! Your new accomplice, CHALLENGER 3, has everything you are looking for in a machine!
Three different tail shaft options are offered. Challenger 3’s standard equipment is suitable for use in the front or at the back. This machine can be operated on either 540 rpm or 1000 rpm without any modifications
Capasity : 25-40 ton/hour
Minimum Power required : 75 Hp / 56 Kw
Number of Throwing Pallets : 12 pcs
Number of Cutter Blades : 12 Pcs
Number of shredder blades : 12 pcs
Power Transmission System : Gearbox
Pto Tour : 540-750-1000 (d/dk)
Shredding : Size 4 mm
Working Width : 125 cm (Single row)
Tractor Working Position : Side-Rear-Front
Tire Sizes : 165x70x13
Length : 1870 mm
Height : 4135 mm
Height (folded) : 2230 mm
Width : 2900 mm
Weight : 1350 Kg
Capacity : 8-15 Ton/Hour
Minimum Power Required : 40 Hp / 30 Kw
Number of Throw Pallet : 6 pcs
Number of Cutter Blades : 12 pcs
Number of shredder blades : 12 pcs
Power Transmission System : Gearbox
Pto Tour : 540 (tour/min)
Shredding : Size 5-10 mm
Working Width : 50 cm (Single row)
Working Position with Tractor : Side (Right)
Tire Sizes : 16×6,50-8 (170/60-8)
Lenght : 2500 mm
Height : 3200 mm
Height (Folded) : 2000 mm
Width : 2350 mm
Weight : 590 Kg
Length On Road 2770 mm
Length in Work Condition 2100 mm
Width on road 2100 mm
Width in Work Condition 3075 mm
Height 3520 mm
Weight (kg) 500 kg
Power Requirement 45 hp
Number of Blades 21 adet
Stable knife 2 pcs
Wheel Options 4,50-10 KNK-52-4PR
Flywheel Tour 1350 tour/min. (rpm)
PTO Tour 540 tour/min. (rpm)
Working capacity 17 Ton/hour
Working Width 130 cm
Length On Road 2970 mm
Length in Work Condition 2100 mm
Width on road 2100 mm
Width in Work Condition 3275 mm
Height 3520 mm
Weight (kg) 620 kg
Power Requirement 45 hp
Number of Blades 24 adet
Stable knife 2 pcs
Wheel Options 4,50-10 KNK-52-4PR
Flywheel Tour 1350 tour/min. (rpm)
PTO Tour 540 tour/min. (rpm)
Working capacity 19,5 Ton/hour
Working Width 150 cm
| Model | Celikel CALABRIA 1800 |
| Length | 2400 mm |
| Width | 2840 mm |
| Height | 3700 mm |
| The weight | 975 kg |
| Required power | 80 hp |
| Number of knives | 20 pcs |
POWER REQUIREMENT (MIN – MAX) 45 – 60 HP
WORKING WIDTH 1500 mm
ROTOR KNIFE NUMBER 36 pcs
CHOPPING KNIFE NUMBER 10 pcs
SWEEPING PADDLE NUMBER 10 pcs
FIXED BLADES NUMBER 6 pcs
WHEEL SIZES 185X65XR14
ROTOR REV NUMBER 1150 RPM
CHOPPING KNIFE REV NUMBER 1620 RPM
WEIGHT 1180 KG
PTO REV NUMBER 540 RPM
WORK CAPACITY * 20 tons / hour 24
WIDTH (WORK POSITION) 2700 mm
HEIGHT (WORK POSITION) 4420 mm
LENGHT (WORK POSITION) 4500 mm
WIDTH (ROAD POSITION) 3275 mm
HEIGHT (ROAD POSITION) 2650 mm
CHOPPING SIZE (ADJUSTABLE) 20 – 70 mm
REAPING HEIGHT (ADJUSTABLE) 50-150 mm
TRACTOR DEPENDENT HYDRAULIC Standard
TRACTOR INDEPENDENT HYDRAULIC Optional
360° ROTARY CHIMNEY Optional
160° ROTARY CHIMNEY Standard
DOUBLE STAGE HAT Standard
POWER REQUIREMENT (MIN – MAX) 60 – 80 HP
WORKING WIDTH 1800 mm
ROTOR KNIFE NUMBER 48 pcs
CHOPPING KNIFE NUMBER 10 pcs
SWEEPING PADDLE NUMBER 10 pcs
FIXED BLADES NUMBER 6 pcs
WHEEL SIZES 185X65XR14
ROTOR REV NUMBER 1150 RPM
CHOPPING KNIFE REV NUMBER 1620 RPM
WEIGHT 1245 KG
PTO REV NUMBER 540 RPM
WORK CAPACITY * 24 tons / hour
WIDTH (WORK POSITION) 3000 mm
HEIGHT (WORK POSITION) 4420 mm
LENGHT (WORK POSITION) 4500 mm
WIDTH (ROAD POSITION) 3375 mm
HEIGHT (ROAD POSITION) 2650 mm
CHOPPING SIZE (ADJUSTABLE) 20 – 70 mm
REAPING HEIGHT (ADJUSTABLE) 50-150 mm
TRACTOR DEPENDENT HYDRAULIC Standard
TRACTOR INDEPENDENT HYDRAULIC Optional
360° ROTARY CHIMNEY Optional
160° ROTARY CHIMNEY Standard
DOUBLE STAGE HAT Standard
POWER REQUIREMENT (MIN – MAX) 80 – 110 HP
WORKING WIDTH 2100 mm
ROTOR KNIFE NUMBER 56 pcs
CHOPPING KNIFE NUMBER 10 pcs
SWEEPING PADDLE NUMBER 10 pcs
FIXED BLADES NUMBER 6 pcs
WHEEL SIZES 185X65XR14
ROTOR REV NUMBER 1150 RPM
CHOPPING KNIFE REV NUMBER 1620 RPM
WEIGHT 1310 KG
PTO REV NUMBER 540 RPM
WORK CAPACITY * 28 tons / hour
WIDTH (WORK POSITION) 3300 mm
HEIGHT (WORK POSITION) 4420 mm
LENGHT (WORK POSITION) 4500 mm
WIDTH (ROAD POSITION) 3500 mm
HEIGHT (ROAD POSITION) 2650 mm
CHOPPING SIZE (ADJUSTABLE) 20 – 70 mm
REAPING HEIGHT (ADJUSTABLE) 50-150 mm
TRACTOR DEPENDENT HYDRAULIC Standard
TRACTOR INDEPENDENT HYDRAULIC Optional
360° ROTARY CHIMNEY Optional
160° ROTARY CHIMNEY Standard
DOUBLE STAGE HAT Standard
